RESEARCH ARTICLE

Complete genome sequence of serotype 3 Streptococcus suis INT-01, isolated from a domestic pig in Korea

Seon Young Park1,2,#https://orcid.org/0000-0002-1351-7557, In Hwang Kim3,#https://orcid.org/0000-0002-0141-5537, Hyun Jin Yu3https://orcid.org/0000-0001-9930-0318, Hyoung Rok Paik3https://orcid.org/0000-0002-6343-2383, Jee Soo Son3,*https://orcid.org/0000-0003-0094-2105, Ji Hyung Kim1,*https://orcid.org/0000-0002-7921-2625
Author Information & Copyright
1Infectious Disease Research Center, Korea Research Institute of Bioscience and Biotechnology, Daejeon 34141, Korea
2Division of Animal and Dairy Sciences, College of Agriculture and Life Science, Chungnam National University, Daejeon 34134, Korea
3iNtRON Biotechnology, Seongnam 13202, Korea
*Corresponding author: Jee Soo Son, iNtRON Biotechnology, Seongnam 13202, Korea. Tel: +82-31-739-5309, E-mail: jsson@intron.co.kr
*Corresponding author: Ji Hyung Kim, Infectious Disease Research Center, Korea Research Institute of Bioscience and Biotechnology, Daejeon 34141, Korea. Tel: +82-42-879-8272, E-mail: kzh81@kribb.re.kr

#These authors contributed equally to this work.

© Copyright 2021 Korean Society of Animal Science and Technology. This is an Open-Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/4.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.

Received: Nov 26, 2020; Revised: Feb 08, 2021; Accepted: Feb 18, 2021

Published Online: May 31, 2021

Abstract

Streptococcus suis is a major pig pathogen causing severe economic losses to the swine industry. This study aimed to analyze the genome of S. suis strain INT-01 isolated from a domestic pig in Korea. We found that the genome of strain INT-01 contains 2,092,054 bp, with a guanine (G) + cytosine (C) content of 41.3%, and the capsular polysaccharide synthesis locus of this strain is almost identical to that of serotype 3 S. suis strain 4961 isolated from China, suggesting that these isolates can be classified as serotype 3. Genomic analyses revealed that strain INT-01 is an extracellular protein factor (epf)/ muraminidase-released protein (mrp)+/ suilysin (sly)S. suis, which is the most prevalent genotype in Korea, and several virulence-related genes associated with the pathogenicity of S. suis were also detected. The genomic information of strain INT-01 may provide important insights into the development of control strategies against S. suis infections in Korea.

Keywords: Streptococcus suis; Pathogen; Genotype; Control strategy; Swine industry

Streptococcus suis is a major pig pathogen causing severe economic losses to the swine industry and is considered a prominent zoonotic agent [1]. Thus far, 35 capsular serotypes have been reported for this species, and its distribution among pigs geographically varies [2]. Several virulence factors have been reported for S. suis, and extracellular protein factor (epf), muraminidase-released protein (mrp), and suilysin (sly) are considered to be the major virulence-associated genes underlying the pathogenesis of this bacterium [3]. Although a recent study has reported that serotype 3, with the epf/mrp+/sly genotype, is the most prevalent serotype among Korean isolates [1], its genomic characteristics remain unknown.

In this study, strain INT-01 was isolated in 2018 from the tonsillar swab of a growing pig with respiratory clinical signs that had been reared at a private farm in Yesan (Chungcheongnam-do, Korea). The α-hemolytic isolate displayed 99.7% 16S rRNA identity to S. suis S735T (AY585196), thus suggesting that strain INT-01 is a member of S. suis. The antimicrobial susceptibility of strain INT-01 was evaluated according to the testing guidelines and interpretive breakpoints in the M100S document of the Clinical and Laboratory Standards Institute [4]. The isolate was resistant to tetracycline, erythromycin, gentamicin, lincomycin, and levofloxacin. Its genome was sequenced using the PacBio RS II system (Pacific Biosciences, Menlo Park, CA, USA) with P6-C4 chemistry by constructing a 20 kb SMRTbellTM template library, using the DNA/polymerase binding kit P6 (Pacific Biosciences) in accordance with the manufacturer’s instructions. Genome assembly of the filtered reads (1,245,264,540 bp, 153,790 reads, N50, 10,696 bp) was performed using the PacBio HGAP (v.2.3) pipeline with default settings, using the de novo assembly protocol, and the reads (2,113,334 bp, 409×) were polished using Quiver. Annotation was performed using the Prokaryotic Genome Annotation Pipeline (National Center for Biotechnology Information, http://www.ncbi.nlm.nih.gov/books/NBK174280/).

The genome of INT-01 was found to comprise 2,092,054 bp (41.3% guanine [G] + cytosine [C] content), encoding 2,054 coding sequences, 12 rRNAs, 57 tRNAs, and 4 non-coding RNAs (Table 1). Genome similarities among INT-01 and other S. suis strains were assessed using ANI Calculator [5], and the genome was found to be 96.9% similar to that of S. suis S735T (NC_018526, serotype 2); furthermore, this strain is most similar to S. suis ST3 (NC_015433, serotype 3) [6,7] (Fig. 1). Moreover, the capsular polysaccharide synthesis (cps) locus of INT-01 is almost identical (> 99.9%) to that of strain 4961 (JF273646, serotype 3), thus suggesting that INT-01 can be classified as serotype 3 [8].

Table 1. Characteristics of the Streptococcus suis strain INT-01 genome
Features Value
Genome size (bp) 2,092,054
G+C content (%) 41.3
Contigs 1
Total genes 2,073
 tRNAs 58
 rRNAs (5S, 16S, 23S) 4, 4, 4
 ncRNAs 4
 Protein-coding genes 1,929
 Pseudogenes 70

G, guanine; C, cytosine.

Download Excel Table
jast-63-3-662-g1
Fig. 1. Overall genome relatedness and heatmaps on the basis of OrthoANI values determined with the available complete genomes of Streptococcus suis INT-01 and other species in the S. suis strains. The result of each two-strain comparison is provided, where the diagonals departing from each strain meet, e.g., the OrthoANI value between S. suis INT-01 and S. suis ST3 is 99.95% (2-column fitting image).
Download Original Figure

Major virulence-associated genes in INT-01 were manually compared with those of the S. suis strains available in the GenBank database, and other virulence-associated and antibiotic-resistant genes were screened as previously described [9]. Consequently, strain INT-01 was identified to be an epf/mrp+/slyS. suis, which is the most prevalent genotype in Korea [1]. Additionally, several virulence-associated factors of the genus Streptococcus, including choline-binding protein D (cbpD), fibronectin/fibrinogen-binding proteins (fbp54/pavA), glyceraldehyde-3-phosphate dehydrogenase (plr/gapA), extracellular hyaluronidase (hylA), periplasmic serine endoprotease (htrA/degP), trigger factor (tig/ropA), and zinc metalloproteinase (zmpC) were detected. However, no genetic determinants associated with antibiotic resistance were detected. These results suggest that other unknown resistance determinants may present in INT-01, warranting further investigation. To our knowledge, this is the first study to report the genome of S. suis from Korea. The present results potentially provide important insights into the development of control strategies against S. suis infections by providing the genomic information of the most prevalent type of the pig pathogen in Korea.

Streptococcus suis INT-01 has been deposited in the Culture Collection of Antimicrobial Resistant Microbes (CCARM) as CCARM4634, and its genome has been deposited in the DDBJ/ENA/GenBank database under accession number CP041994.1.

Competing interests

No potential conflict of interest relevant to this article was reported.

Funding sources

This study was funded by the KRIBB Initiative programs, the National Research Foundation (NRF) of Korea (NRF-2020R1I1A2068827), the Collaborative Genome Program of the Korea Institute of Marine Science and Technology Promotion (20180430) funded by the Ministry of Oceans and Fisheries, and ATC Program grant 10076996 from the Ministry of Trade, Industry, and Energy of Korea.

Acknowledgements

Not applicable.

Availability of data and material

Upon reasonable request, the datasets of this study can be available from the corresponding author. Streptococcus suis INT-01 has been deposited in the Culture Collection of Antimicrobial Resistant Microbes (CCARM) as CCARM4634.

Authors’ contributions

Conceptualization: Son JS, Kim JH.

Data curation: Park SY, Kim IH, Yu HJ.

Formal analysis: Park SY, Kim IH.

Methodology: Park SY, Kim IH, Yu HJ, Paik HR.

Software: Park SY, Kim IH.

Validation: Park SY, Kim IH, Paik HR.

Investigation: Park SY, Kim IH, Kim JH.

Writing - original draft: Park SY, Kim IH, Kim JH.

Writing - review & editing: Son JS, Kim JH.

Ethics approval and consent to participate

This article does not require IRB/IACUC approval because there are no human or animal participants.

REFERENCES

1.

Oh SI, Jeon AB, Jung BY, Byun JW, Gottschalk M, Kim A, et al. Capsular serotypes, virulence-associated genes and antimicrobial susceptibility of Streptococcus suis isolates from pigs in Korea. J Vet Med Sci. 2017; 79:780-7

2.

Athey TBT, Teatero S, Lacouture S, Takamatsu D, Gottschalk M, Fittipaldi N. Determining Streptococcus suis serotype from short-read whole-genome sequencing data. BMC Microbiol. 2016; 16:162

3.

Li LL, Liao XP, Sun J, Yang YR, Liu BT, Yang SS, et al. Antimicrobial resistance, serotypes, and virulence factors of Streptococcus suis isolates from diseased pigs. Foodborne Pathog Dis. 2012; 9:583-8

4.

Clinical and Laboratory Standards Institute [CLSI]. performance standards for antimicrobial susceptibility testing M100S. 29th ed Wayne, PA: CLSI. 2018

5.

Lee I, Ouk Kim Y, Park SC, Chun J. OrthoANI: an improved algorithm and software for calculating average nucleotide identity. Int J Syst Evol Microbiol. 2016; 66:1100-3

6.

Hu P, Yang M, Zhang A, Wu J, Chen B, Hua Y, et al. Complete genome sequence of Streptococcus suis serotype 3 strain ST3. J Bacteriol. 2011; 193:3428-9

7.

Goyette-Desjardins G, Auger JP, Xu J, Segura M, Gottschalk M. Streptococcus suis, an important pig pathogen and emerging zoonotic agent—an update on the worldwide distribution based on serotyping and sequence typing. Emerg Microbes Infect. 2014; 3:1-20

8.

Wang K, Fan W, Cai L, Huang B, Lu C. Genetic analysis of the capsular polysaccharide synthesis locus in 15 Streptococcus suis serotypes. FEMS Microbiol Lett. 2011; 324:117-24

9.

Lee K, Kim HK, Sohn H, Cho Y, Choi YM, Jeong DG, et al. Genomic insights into Photobacterium damselae subsp. damselae strain KC-Na-1, isolated from the finless porpoise (Neophocaena asiaeorientalis). Mar Genom. 2018; 37:26-30
