RESEARCH ARTICLE

Effects of radish powder concentration and incubation time on the physicochemical characteristics of alternatively cured pork products

Su Min Bae1https://orcid.org/0000-0002-9367-4594, Jae Hyeong Choi1https://orcid.org/0000-0002-9158-2418, Jong Youn Jeong1,*https://orcid.org/0000-0001-5284-4510
Author Information & Copyright
1School of Food Biotechnology & Nutrition, Kyungsung University, Busan 48434, Korea
*Corresponding author: Jong Youn Jeong, School of Food Biotechnology & Nutrition, Kyungsung University, Busan 48434, Korea., Tel: +82-51-663-4711, E-mail: jeongjy@ks.ac.kr

© Copyright 2020 Korean Society of Animal Science and Technology. This is an Open-Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/4.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.

Received: Aug 27, 2020; Revised: Sep 08, 2020; Accepted: Sep 10, 2020

Published Online: Nov 30, 2020

Abstract

Previous research has indicated that radish powder could be a suitable replacement for chemical nitrite sources in alternatively cured meat products. However, the effects of radish powder level on the physicochemical properties of cured meat have not been systematically studied. In this study, we aimed to investigate the effects of varying concentrations of radish powder and incubation time on the physicochemical properties and cured meat pigments of alternatively cured meat products. We divided our experimental setup into seven groups with different radish powder concentrations and incubation times: control (0.01% sodium nitrite), treatment 1 (0.15% radish powder and 2 h incubation), treatment 2 (0.15% radish powder and 4 h incubation), treatment 3 (0.30% radish powder and 2 h incubation), treatment 4 (0.30% radish powder and 4 h incubation), treatment 5 (0.30% celery powder and 2 h incubation), and treatment 6 (0.30% celery powder and 4 h incubation). The cooking yield, CIE a* values (redness), and total pigment levels were not significantly different (p > 0.05) between any of the alternatively cured treatments and the control. However, when 0.30% radish powder or celery powder was added to the products, the CIE b* values increased significantly (p < 0.05) with incubation time. At the same vegetable concentration, the nitrite content, nitrosyl hemochrome, and curing efficiency also increased significantly (p < 0.05) as the incubation time increased from 2 to 4 h, regardless of the types of vegetable powder. Among the meat products cured with radish powder, treatment 4 showed the highest increase in residual nitrite content, nitrosyl hemochrome content, and curing efficiency, but showed decreased lipid oxidation. Our results suggest that increased concentrations of radish powder and longer incubation times would be more suitable for producing alternatively cured meat products comparable to traditionally cured products treated with synthetic nitrite.

Keywords: Radish powder; Incubation time; Nitrite replacement; Alternatively cured meat products

INTRODUCTION

Nitrite is used in the curing of various meat products to improve flavor and color and to prevent lipid oxidation [13]. Nitrite also helps control contamination by anaerobic bacteria, especially Clostridium botulinum, and it suppresses other microorganisms such as Listeria monocytogenes [1,4]. Despite these benefits, nitrite-treated meat products attract negative consumer perception due to the potential for the formation of nitrosamines [5]. Therefore, researchers have long been attempting to identify suitable replacements for nitrite in meat curing [611]. Although no alternatives have been found to completely replace synthetic nitrite, some vegetables that contain considerable amounts of nitrate are used today as natural replacements for nitrite/nitrate in alternatively cured processed meat or naturally cured processed meat [4,12]. In previous studies, celery, parsley, Swiss chard, spinach, and cabbage have been found to be suitable natural replacements for synthetic nitrite [10,1316].

Radish has high nitrate contents ranging from 1,878 to 6,260 ppm [12,17,18]. It also contains bioactive compounds such as ascorbic acid, polyphenols, and flavonoids [19]. Furthermore, as radish roots are usually white in color [19,20], its effect on the color of the final meat product is expected to be less drastic than that of other leafy vegetables. Thus, radish powder may be a useful natural replacement for synthetic nitrite in alternatively cured meat products. However, thus far, there have been no studies on the effects of different concentrations of radish powder on cured meat products.

To generate nitrite from the natural nitrate in vegetables such as radish, specific microorganisms that produce nitrate reductases are required; Staphylococcus carnosus and S. xylosus are examples of such microbes, among others [1]. Optimal temperature and incubation time are necessary to allow the conversion of nitrate to nitrite by these bacteria, prior to thermal processing of the meat products. The importance of incubation time for the proper development of desirable cured meat characteristics has been shown in previous studies [10,11,21]. Sindelar et al. [11] reported that a longer incubation time (120 min instead of 30 min) was more critical than a higher concentration of vegetable powders (0.20% or 0.40%) for the production of indirectly cured sausages comparable to sodium nitrite-treated ones. Terns et al. [21] also found that increasing the incubation time was more important for improving the properties of cured meat than increasing the amount of starter culture used (0.01% or 0.02%). However, indirectly cured meat products incubated for less than 2 hours show lower residual nitrite levels than sodium nitrite-treated controls [11,14,22]. It is possible that longer incubation times are required to produce sufficient nitrite to achieve the desired levels of cured meat color characteristics in alternatively cured products. However, so far, there have not been any systematic studies on the combined effects of longer incubation time at different concentrations of vegetable powders on the quality of alternatively cured meat products. In this study, we investigated the effects of different concentrations of radish powder and incubation times on the physicochemical properties and cured meat pigments of alternatively cured meat products, by comparing with products with sodium nitrite or commercially available celery powders.

MATERIALS AND METHODS

The preparation of radish powder

To manufacture radish powder with high concentrations of nitrate, radishes were purchased from five provinces of Korea (Chungcheong-do, Gangwon-do, Gyeonggi-do, Gyeongsang-do, and Jeolla-do) and randomly selected (approximately 10 kg/region) for the experiment. The selected radish roots were cut into cubes of approximately 2 × 3 × 3 cm3 after washing, peeling, and removing the inedible portions. These radish cubes were blended using a food cutter (C6 VV, Sirman, Marsango, Italy) for 6 min, vacuum-packed in nylon/polyethylene bags (~500 g each), and stored in a freezer (C110AHB, LG Electronics, Changwon, Korea) at −24°C prior to hot air drying. Before drying, the nitrate and nitrite ion contents in the homogenized radish were measured. The frozen radishes were placed on a Teflon sheet (TBS-345, Alphaflon, Seoul, Korea) and dried at 60°C for 12 hours in a food dryer (EN-FO-392S, Enex science, Goyang, Korea). The dried radishes were then pulverized with a blender (51BL30, Waring Commercial, Torrington, CT, USA) for 3 min and filtered through a 30-mesh sieve (Test sieve BS0600, Chunggye Sieve, Gunpo, Korea). The resulting radish powder was vacuum-packed and stored at −24°C until use. The nitrate and nitrite ion content and pH of the radish powder were measured prior to the meat processing.

The preparation of raw materials and processing of cured meat products

Fresh pork ham (M. biceps femoris, M. semitendinosus, and M. semimembranosus) and backfat were purchased from a local meat processor (Pukyung Pig Farmers Livestock, Kimhae, Korea) at 24–48 hours postmortem. After removing the intermuscular fat and visible connective tissues from the pork ham, the lean pork meat and backfat were sequentially ground using a chopper (TC-22 Elegant plus, Tre Spade, Torino, Italy) with an 8-mm and a 3-mm plate, respectively. Celery powder (VegStable 502, Florida Food Products, Eustis, FL, USA) with a nitrate ion content of 23,375 ppm (equivalent to 32,020 ppm sodium nitrate), a starter culture (CS 299, CHR Hansen, Milwaukee, WI, USA) of Staphylococcus carnosus, sodium nitrite (S2252, Sigma-Aldrich, St. Louis, MO, USA), and sodium ascorbate (#35268, Acros Organics, Geel, Belgium) were obtained from commercial suppliers.

Ground pork meat and fat (total batches of 30 kg per trial) were randomly assigned to the control group and six treatment groups (Table 1): control group, 0.01% sodium nitrite; treatment 1, 0.15% radish powder and 2 hours incubation; treatment 2, 0.15% radish powder and 4 hours incubation; treatment 3, 0.30% radish powder and 2 hours incubation; treatment 4, 0.30% radish powder and 4 hours incubation; treatment 5, 0.30% celery powder and 2 hours incubation; and treatment 6, 0.30% celery powder and 4 hours incubation. In the alternatively cured treatments, the starter culture was added at a concentration of 10% of the amount of radish powder or celery powder added. The ground pork meat and backfat were mixed with NaCl, sodium tripolyphosphate, vegetable powders or sodium nitrite (depending on treatments), other ingredients, and ice/water using a mixer (5K5SS, Whirlpool, St. Joseph, MI, USA) for 10 min. The mixtures from each batch were stuffed into conical tubes (approximately 50 g each), which were then centrifuged at 2,000 ×g for 10 min (Combi R515, Hanil Science Industrial, Incheon, Korea) to remove air pockets. The controls were placed in a refrigerator at 2°C–3°C for 1 hour and the treatment groups were kept in an incubator (C-IB4, Changshin Science, Pocheon, Korea) at 38°C for 2 hours or 4 hours, depending on the treatment group. The tubes were then cooked to reach an internal temperature of 75°C in a water bath (MaXturdy 45, Daihan Scientific, Wonju, Korea) at 90°C set. The cooked samples were immediately cooled for 20 min on slurry ice and stored at 2°C−3°C in the dark until analysis. All experiments were performed in triplicate.

Table 1. The formulation for alternatively cured meat products formulated with different types and concentrations of vegetable powders
Ingredients (%) Control1) Treatments 1 and 2 Treatments 3 and 4 Treatments 5 and 6
Pork ham 70.00 70.00 70.00 70.00
Pork backfat 15.00 15.00 15.00 15.00
Ice/water 15.00 15.00 15.00 15.00
Sub total 100.00 100.00 100.00 100.00
NaCl 1.50 1.50 1.50 1.50
Sugar 1.00 1.00 1.00 1.00
Sodium tripolyphosphate 0.30 0.30 0.30 0.30
Sodium ascorbate 0.05 0.05 0.05 0.05
Mustard powder 0.30 0.30 0.30 0.30
Black pepper 0.25 0.25 0.25 0.25
Monosodium glutamate 0.10 0.10 0.10 0.10
Onion powder 0.10 0.10 0.10 0.10
Garlic powder 0.10 0.10 0.10 0.10
Sodium nitrite 0.01 0.00 0.00 0.00
Radish powder 0.00 0.15 0.30 0.00
Celery powder 0.00 0.00 0.00 0.30
Starter culture 0.00 0.015 0.03 0.03
Total 103.71 103.865 104.03 104.03

1) Control, 0.01% sodium nitrite; Treatment 1, 0.15% radish powder and 2 hours incubation; Treatment 2, 0.15% radish powder and 4 hours incubation; Treatment 3, 0.30% radish powder and 2 hours incubation; Treatment 4, 0.30% radish powder and 4 hours incubation; Treatment 5, 0.30% celery powder and 2 hours incubation; Treatment 6, 0.30% celery powder and 4 hours incubation.

Download Excel Table
The pH measurement

A pH meter (Accumet AB150, Thermo Fisher Scientific, Waltham, MA, USA) was used to measure the pH on five grams of the fresh radish, the radish powder, and the cooked meat samples homogenized in 45 mL of distilled water.

Cooking yield determination

Each meat sample in the conical tube was weighed before cooking, and then weighed again after cooking and cooling. The cooking yield was determined using the equation:

Cooking yield ( % ) = Sample weight after cooking Sample weight before cooking × 100
CIE color measurement

The Commission Internationale de l’Eclairage (CIE) L* (lightness), a* (redness), and b* (yellowness) values were measured on the freshly cut surfaces of each cooked sample using a colorimeter (Chroma Meter CR-400, illuminant C, 2° standard observer; Konica Minolta Sensing, Osaka, Japan) calibrated with a white plate (L* 94.90, a* –0.39, b* 3.88).

Nitrate and nitrite ion content measurement for fresh radish and powder

The nitrate (NO3) and nitrite (NO2) ion contents in the homogenized radish and prepared radish powder were determined using the zinc reduction method described by Merino [23]. The observed results were converted in terms of the concentration of sodium nitrite and expressed as ppm.

Residual nitrite content analysis for cured meat products

The residual nitrite content in the cooked meat samples was determined by the AOAC method [24]. The results were reported as ppm by a standard curve using sodium nitrite (S2252, Sigma-Aldrich).

Nitrosyl hemochrome, total pigment and curing efficiency analysis

Nitrosyl hemochrome and total pigment content in the cooked cured products were determined after extraction in 80% acetone and acidified acetone using a method established by Hornsey [25]. The nitrosyl hemochrome concentration (ppm) was calculated as A540 × 290. The total pigment concentration (ppm) was calculated as A640 × 680. Finally, curing efficiency (%) was calculated using the equation:

Curing efficiency ( % ) = Nitrosyl hemochrome content Total pigment content × 100
Determination of thiobarbituric acid reactive substances (TBARS)

Malondialdehyde (MDA) content was measured based on 2-thiobarbituric acid reactive substances (TBARS) values using a distillation method reported by Tarladgis et al. [26]. The TBARS values were reported as milligrams of MDA per kilogram of the cooked samples (mg MDA/kg).

Statistical analysis

All experiments were performed in triplicate. The experimental design was a randomized block design with seven groups (one control group and six treatment groups). Data were statistically analyzed using the Proc GLM (general linear model) in the SAS program (Statistical Analysis System 2012, version 9.4, SAS Institute, Cary, NC, USA). If the model revealed a significant difference (p < 0.05), the significance of the means was further separated using Tukey’s multiple comparison test.

RESULTS AND DISCUSSION

Nitrate content, nitrite content, and pH of radish and radish powder

The ground raw radish had 2,619 ppm nitrate ion and 0.06 ppm nitrite ion (Table 2). The nitrate and nitrite ion content in radishes varied between regions, and this may be attributed to variations in cultivar type, environmental factors, and fertilizers [12,27]. Chung et al. [17] reported that radish from Korea contained 1,878 ppm nitrate ion and 0.80 ppm nitrite ion, which were lower than the values we obtained. Raczuk et al. [18] found that radishes from Poland had, on average, 2,132 ppm nitrate ion and 1.90 ppm nitrite ion. After hot air drying, the radish powder had 55,935 ppm nitrate ion (equivalent to 76,623 ppm sodium nitrate) and 0.09 ppm nitrite ion (equivalent to 0.14 ppm sodium nitrite) (Table 2). This increase in nitrate and nitrite ion contents could be attributed to the evaporation of moisture due to the drying process [14,22,28].

Table 2. The nitrate ion content, sodium nitrate content, nitrite ion content, sodium nitrite content, and pH in radish and radish powder
Traits Raw radish Radish powder
Nitrate ion content (NO3, ppm) 2,619 ± 52.28 55,935 ± 2,456
Sodium nitrate content (NaNO3, ppm) 3,588 ± 71.62 76,623 ± 3,365
Nitrite ion content (NO2, ppm) 0.06 ± 0.04 0.09 ± 0.03
Sodium nitrite content (NaNO2, ppm) 0.09 ± 0.04 0.14 ± 0.05
pH 5.92 ± 0.05 5.09 ± 0.99
Download Excel Table

Commercially available celery powder or juice powder typically contains about 30,000 ppm nitrate [2]. Our results indicated that the radish powder we prepared could have sufficient nitrate content for use in the production of alternatively cured meat products. The radish and radish powder had a pH of 5.92 and 5.09, respectively (Table 2). Similarly, Jeong et al. [14] found that dried powder prepared from radish grown in the Jeolla-do region of Korea had a pH of 5.14.

Physicochemical properties of alternatively cured pork products

The cooking yield ranged from 99.43% to 99.53% and was not affected (p > 0.05) by the incubation time or the concentration of radish powder or celery powder added (Table 3). These results were consistent with those of Banerjee et al. [29], who found that nuggets treated with different concentrations of broccoli powder showed no difference in cooking yield. However, our results disagree with those of Choi et al. [6], who reported that naturally cured products treated with white kimchi powder and celery powder had lower cooking yields than sodium nitrite-treated controls. This difference in results could be attributed to the difference in phosphate levels in the products. Unlike in our study, Choi et al. [6] did not include phosphate in their product formulation. Regarding the incubation time, our results are consistent with those of Sindelar et al. [30], who reported that incubation time did not affect the cooking yield in indirectly cured jerkies.

Table 3. Effects of radish powder on cooking yield, pH values, and CIE color values of alternatively cured meat products
Treatments1) Cooking yield (%) pH CIE L* CIE a* CIE b*
Control 99.50 ± 0.04 6.10 ± 0.01D 66.32 ± 0.17B 8.55 ± 0.10 8.05 ± 0.09C
Treatment 1 99.53 ± 0.04 6.18 ± 0.01A 67.25 ± 0.20A 8.31 ± 0.10 7.90 ± 0.06C
Treatment 2 99.40 ± 0.02 6.19 ± 0.01A 66.83 ± 0.11AB 8.44 ± 0.12 8.08 ± 0.07C
Treatment 3 99.47 ± 0.02 6.14 ± 0.01BC 67.03 ± 0.23A 8.44 ± 0.21 7.97 ± 0.11C
Treatment 4 99.43 ± 0.01 6.15 ± 0.01B 67.03 ± 0.16AB 8.42 ± 0.09 8.36 ± 0.07B
Treatment 5 99.53 ± 0.02 6.13 ± 0.01BC 67.18 ± 0.16A 8.30 ± 0.06 8.37 ± 0.10B
Treatment 6 99.45 ± 0.01 6.12 ± 0.01CD 66.74 ± 0.19AB 8.47 ± 0.14 8.66 ± 0.08A

All values are means ± SE.

Number of observations in the treatments, n = 15 (cooking yield); 6 (pH); 12 (CIE L*); 12 (CIE a*); 12 (CIE b*).

1) Control, 0.01% sodium nitrite; Treatment 1, 0.15% radish powder and 2 hours incubation; Treatment 2, 0.15% radish powder and 4 hours incubation; Treatment 3, 0.30% radish powder and 2 hours incubation; Treatment 4, 0.30% radish powder and 4 hours incubation; Treatment 5, 0.30% celery powder and 2 hours incubation; Treatment 6, 0.30% celery powder and 4 hours incubation.

A–D Mean within a column with different superscript letters are significantly different (p < 0.05).

Download Excel Table

All alternatively cured pork products had significantly higher (p < 0.05) pH than the controls, except for treatment 6 (0.30% celery powder and 4 hours incubation time) (Table 3). Jeong et al. [14] reported similar results; they found that cured pork products treated with Chinese cabbage, radish, or spinach powder showed higher pH than nitrite-added controls. In our study, products treated with 0.15% radish powder (treatments 1 and 2) had higher pH than those treated with 0.30% radish powder (treatments 3 and 4) or 0.30% celery powder (treatments 5 and 6), suggesting that the pH in alternatively cured products decreased as the concentration of vegetable powders increased. However, the incubation time did not affect the pH of the alternatively cured products, irrespective of the concentration of the vegetable powders.

The CIE L* (lightness), a* (redness), and b* (yellowness) values of alternatively cured meat products in this study are shown in Table 3. There were no differences (p > 0.05) in CIE L* values between the naturally cured pork products, suggesting that the types and levels of vegetable powder added and the incubation time did not affect (p > 0.05) CIE L* values. However, cured products incubated for 2 hours (treatments 1, 3, and 5) had CIE L* values higher (p < 0.05) than those of the control, while treatments 2, 4, and 6, which were incubated for 4 hours, had similar CIE L* values as the control. These results are consistent with those of Sindelar et al. [11], who found that the CIE L* values of emulsified cooked sausages were not affected by the concentration of the vegetable juice powder (0.2% or 0.4%) or the incubation time (30 min or 120 min). In this study, CIE a* values ranged from 8.30 to 8.55, with no significant differences (p > 0.05) between the control and the treatments. Interestingly, despite the difference in concentration of added vegetable powder, cured pork products with 0.15% radish powder (treatments 1 and 2) and those with 0.30% radish or celery powder (treatments 3–6) had similar redness. Similar results were reported by Choi et al. [6], who found that using different concentrations (0.2% and 0.4%) of white kimchi powder in combination with a nitrate-reducing starter culture and incubating for 2 hours resulted in similar CIE a* values in alternatively cured meat products. Furthermore, the incubation time (2 hours and 4 hours) did not affect the CIE a* values of the alternatively cured pork products in our study, regardless of the concentration of the vegetable powders. These results indicate that the use of radish powder, along with a short incubation time of 2 hours could produce a redness in alternatively cured meat products comparable to that in traditionally cured products and those treated with commercially available celery powders. CIE b* values of cured products treated with celery powder (treatments 5 and 6) were higher (p < 0.05) than the control, but no differences (p > 0.05) in CIE b* values were observed between the control and other treatments, except treatment 4. These results were consistent with those of Jeong et al. [14], who reported that when cured pork products were treated with different vegetable powders and a starter culture, followed by incubating for 2 hours, the yellowness of the final products were increased after treatment with Chinese cabbage or spinach powder, but those treated with radish powder had similar CIE b* values to the nitrite-added control. Furthermore, Krause et al. [31] reported that uncured sliced ham treated with vegetable juice powder and a starter culture showed higher b* values than the sodium nitrite-treated control, which is consistent with our results for the celery powder treatments. The increased yellowness in the products treated with celery powder may be attributed to the presence of yellow pigments like carotenoids in celery [32]. We also observed that the incubation time did not affect CIE b* values in treatments 1 and 2 (0.15% radish powder). However, in products treated with 0.3% radish powder and 0.3% celery powder, the CIE b* values increased (p < 0.05) with incubation time, which was consistent with the observations of Kim et al. [13] in cured pork loins incubated with spinach and a starter culture.

The products treated with 0.30% radish powder (treatment 4) were found to have higher (p < 0.05) residual nitrite contents than those treated with 0.15% radish powder (treatment 2) (Table 4). Interestingly, treatment 4 (0.30% radish powder) resulted in a higher residual nitrite content than treatment 6 (0.30% celery powder), which may be attributed to the relatively high nitrate content of radish powder prepared for our study. Thus, among the vegetable powder treatments, treatment 4 had the highest (p < 0.05) residual nitrite content, which was not different (p > 0.05) from that of the sodium nitrite-treated control. When alternatively cured products were incubated for 2 hours, the residual nitrite contents in treatments 1, 3, and 5 were lower (p < 0.05) than that in the control. However, there was no difference (p > 0.05) between the residual nitrite contents in treatments 3 and 5, while treatment 1 had a lower (p < 0.05) residual nitrite content than treatment 5. However, when the incubation period was increased (4 hours), residual nitrite content also increased (p < 0.05) in all cases (treatments 2, 4, and 6). These results were consistent with previous studies on cooked sausages and hams, which showed that residual nitrite content increased with incubation time [11,31]. Thus, our results indicate that sufficient nitrate concentrations in the vegetable powder and ample incubation time for converting nitrate to nitrite are critical for achieving high-quality alternatively cured meat products. Radish powder may be a promising natural source of nitrite/nitrate, and its addition to alternatively cured products may result in meat products comparable to conventionally cured products and products treated with commercially available celery powder.

Table 4. Effects of radish powder on residual nitrite, nitrosyl hemochrome, total pigments, curing efficiency, and TBARS of alternatively cured meat products
Treatments1) Residual nitrite (ppm) Nitrosyl hemochrome (ppm) Total pigment (ppm) Curing efficiency (%) TBARS (mg MAD/kg)
Control 41.56 ± 1.12A 34.80 ± 0.21AB 46.58 ± 0.29 74.71 ± 0.13B 0.088 ± 0.005B
Treatment 1 7.04 ± 0.88E 31.47 ± 0.36D 45.73 ± 0.21 68.79 ± 0.52D 0.138 ± 0.006A
Treatment 2 18.14 ± 0.27C 34.29 ± 0.12BC 45.90 ± 0.13 74.72 ± 0.37B 0.121 ± 0.006A
Treatment 3 9.19 ± 0.27DE 33.42 ± 0.57C 45.73 ± 0.33 73.05 ± 0.72C 0.119 ± 0.008A
Treatment 4 39.62 ± 1.34A 35.53 ± 0.12AB 45.90 ± 0.28 77.41 ± 0.38A 0.080 ± 0.004B
Treatment 5 10.95 ± 0.78D 33.42 ± 0.22C 46.07 ± 0.33 72.55 ± 0.14C 0.125 ± 0.006A
Treatment 6 21.99 ± 0.24B 35.82 ± 0.05A 46.07 ± 0.28 77.76 ± 0.46A 0.092 ± 0.007B

All values are means ± SE.

Number of observations in the treatments, n = 12 (residual nitrite); 12 (nitrosyl hemochrome); 12 (total pigment); 12 (curing efficiency); 12 (TBARS).

1) Control, 0.01% sodium nitrite; Treatment 1, 0.15% radish powder and 2 hours incubation; Treatment 2: 0.15% radish powder and 4 hours incubation; Treatment 3, 0.30% radish powder and 2 hours incubation; Treatment 4, 0.30% radish powder and 4 hours incubation; Treatment 5, 0.30% celery powder and 2 hours incubation; Treatment 6, 0.30% celery powder and 4 hours incubation.

A–E Mean within a column with different superscript letters are significantly different (p < 0.05).

TBARS, 2-Thiobarbituric acid reactive substances.

Download Excel Table

The nitrosyl hemochrome content in the products were significantly changed (p < 0.05) by the concentration of vegetable powders added and the incubation time (Table 4). When incubated for 2 hours, products treated with 0.15% radish powder (treatment 1) had a lower (p < 0.05) nitrosyl hemochrome content than those treated with 0.30% radish powder (treatment 3) or 0.30% celery powder (treatment 6). Jeong et al. [22] reported a study on ground pork products treated with 0.15%, 0.25%, and 0.35% Chinese cabbage powder or 0.4% celery juice powder and incubated for 2 hours prior to cooking. They found that the cooked products treated with 0.15% Chinese cabbage powder had lower nitrosyl hemochrome than the others, which is consistent with our results. Regardless of the type and concentration of vegetable powders used, the nitrosyl hemochrome content of the alternatively cured products (treatments 2, 4, and 6) increased (p < 0.05) with incubation time, and reached a level similar (p > 0.05) to that in the controls. It has been recognized that incubation time is a key parameter in the production of cured meat treated with vegetable-based ingredients [33]. Therefore, it is possible that the increased amounts of nitrite converted from nitrate by the bacteria during the long incubation periods affect the nitrosyl hemochrome content.

In this study, the total pigment content of the products ranged from 45.73 to 46.58 ppm (Table 4). In a previous study [22], different amounts (0.15%–0.35%) of Chinese cabbage powder were added to pork products, which resulted in total pigment content ranging from 47.18 to 49.13 ppm, similar to our results. However, the total pigment content was not different (p > 0.05) between the different vegetable powder treatments and the control, indicating that it was not affected by the types and concentrations of vegetable powders added or the incubation time. These results are also consistent with those of Posthuma et al. [34], who reported that total pigment content did not change in emulsified beef sausages treated with celery juice powder when the incubation time was increased from 5 min to 120 min.

In the cured meat products treated with radish powder, the curing efficiency was significantly increased (p < 0.05) when the concentration of the radish powder added was increased from 0.15% to 0.30% for both incubation times (2 hours, treatments 1 and 3; 4 hours, treatments 2 and 4) (Table 4). These results were consistent with those of Choi et al. [6], who found that pork products treated with 0.4% white kimchi powder showed a higher curing efficiency than those treated with 0.2% white kimchi powder. Regardless of the types and concentration of vegetable powder added, alternatively cured products incubated for 2 hours had a lower (p < 0.05) curing efficiency than the nitrite-treated control. However, the addition of radish powder or celery powder (regardless of the concentration) to the products followed by incubation for 4 hours resulted in an increased curing efficiency (p < 0.05). While treatment 2 had a similar curing efficiency to the control, the highest curing efficiency was observed in treatments 4 and 6. These results suggest that extended incubation times could increase the curing efficiency in alternatively cured meat products. In addition, when radish powder was added at low concentrations (0.15%) to products, sufficient incubation time would be needed to achieve cured meat characteristics as observed for traditionally cured products.

Alternatively cured products treated with 0.15% radish powder (treatments 1 and 2) were found to have higher (p < 0.05) TBARS values than the control, regardless of the incubation time (Table 4). However, as incubation time increased, the TBARS values in the cured products treated with 0.30% radish powder or celery powder (treatments 4–6) decreased (p < 0.05). There were no significant differences (p > 0.05) in the TBARS values of these treatments and the control. These results could be attributed to the high residual nitrite and nitrosyl hemochrome contents in this study. Lipid oxidation can be inhibited by the antioxidant properties of nitrite [35]. Similarly, Kim et al. [13] found that pork loins with high residual nitrite content showed low TBARS values.

CONCLUSION

In this study, the effects of treating alternatively cured meat products with different concentrations of radish powder, followed by different incubation times, on their physicochemical properties were studied by comparing the meat products with sodium nitrite-treated controls or products treated with commercially available celery powder. Regardless of incubation time, treatment with radish powder improved the redness of the alternatively cured products to levels comparable to that of the sodium nitrite-treated controls. Further, treatment with 0.30% radish power and incubation for 4 hours was effective in improving residual nitrite content, nitrosyl hemochrome content, curing efficiency, and lipid oxidation. Our results indicate that radish powder could make a promising replacement for nitrite/nitrate in meat processing. Further, increased concentrations of radish powder and sufficient incubation time would result in quality characteristics comparable to the products treated with synthetic nitrite or commercially available celery powder. Additionally, in order to facilitate the industrial application of radish powder in alternatively cured meat products, further researches on the sensory properties and microbiological safety during storage should be accompanied.

Competing interests

No potential conflict of interest relevant to this article was reported.

Funding sources

This work was supported by Korea Institute of Planning and Evaluation for Technology in Food, Agriculture and Forestry (IPET) through Innovational Food Product and Natural Food Materials Development Program, funded by Ministry of Agriculture, Food and Rural Affairs (MAFRA) (119028-03-2-HD040), and the BB21+ Project in 2020.

Acknowledgements

Not applicable.

Availability of data and material

Upon reasonable request, the datasets of this study can be available from the corresponding author.

Authors’ contributions

Conceptualization: Jeong JY.

Data curation: Bae SM.

Formal Analysis: Bae SM, Choi JH.

Methodology: Bae SM, Choi JH.

Software: Bae SM, Choi JH.

Validation: Bae SM, Choi JH, Jeong JY.

Investigation: Bae SM, Choi JH, Jeong JY.

Writing – original draft: Bae SM, Choi JH.

Writing – review & editing: Bae SM, Choi JH, Jeong JY.

Ethics approval and consent to participate

This article does not require IRB/IACUC approval because there are no human and animal participants.
