RESEARCH ARTICLE

Physicochemical and textural properties of emulsions prepared from the larvae of the edible insects Tenebrio molitor, Allomyrina dichotoma, and Protaetia brevitarsis seulensis

Tae-Kyung Kim1https://orcid.org/0000-0002-6349-4314, Hae In Yong1https://orcid.org/0000-0003-0970-4496, Samooel Jung2https://orcid.org/0000-0002-8116-188X, Jung-Min Sung1https://orcid.org/0000-0003-1464-2648, Hae Won Jang1,*https://orcid.org/0000-0002-4797-9880, Yun-Sang Choi1,*https://orcid.org/0000-0001-8060-6237
Author Information & Copyright
1Research Group of Food Processing, Korea Food Research Institute, Wanju 55365, Korea
2Division of Animal and Dairy Science, Chungnam National University, Daejeon 34134, Korea
*Corresponding author: Hae Won Jang, Research Group of Food Processing, Korea Food Research Institute, Wanju 55365, Korea. Tel: +82-63-219-9377, E-mail: hwjkfri@kfri.re.kr
*Corresponding author: Yun-Sang Choi, Research Group of Food Processing, Korea Food Research Institute, Wanju 55365, Korea. E-mail: kcys0517@kfri.re.kr

© Copyright 2021 Korean Society of Animal Science and Technology. This is an Open-Access article distributed under the terms of the Creative Commons Attribution Non-Commercial License (http://creativecommons.org/licenses/by-nc/4.0/) which permits unrestricted non-commercial use, distribution, and reproduction in any medium, provided the original work is properly cited.

Received: Oct 01, 2020; Revised: Nov 12, 2020; Accepted: Dec 01, 2020

Published Online: Mar 31, 2021

Abstract

The use of edible insects to replace meat protein is important to ensure future global food security. However, processed foods using edible insects require development to enhance consumer perception. Here, we examined the physicochemical characteristics and rheological properties of emulsions prepared from different edible insect larvae. Three edible insect species (Tenebrio molitor, Allomyrina dichotoma and Protaetia brevitarsis seulensis) were used to prepare larval emulsions that were formulated with 65% of insect larvae, 20% of pork back fat, and 15% ice. The A. dichotoma emulsion had the highest pH and lightness, redness, and yellowness values, while the T. molitor emulsion had the lowest pH and lightness, redness, and yellowness values. The T. molitor emulsion had the highest hardness, gumminess, chewiness, and apparent viscosity values but the lowest springiness and cohesiveness values. According to the sodium dodecyl sulfate-polyacrylamide gel electrophoresis (SDS-PAGE) analysis, T. molitor had the thickest bands, followed by P. brevitarsis seulensis . The differential scanning calorimetry distributions for the T. molitor and A. dichotoma emulsions showed one peak, while that of the P. brevitarsis seulensis emulsion had two peaks. The collective results suggest that T. molitor was the most suitable candidate (of the three tested species) for use as a meat replacement in terms of its physicochemical and rheological properties. It is important that such properties of insect-based emulsions are maintained using various technologies.

Keywords: Differential scanning calorimetry; Emulsion; Edible insect; Larvae; Sodium dodecyl sulfate-polyacrylamide gel electrophoresis (SDS-PAGE)

INTRODUCTION

Edible insects are expected to supplement and possibly replace traditional meat proteins in many parts of the world. Some studies have assessed the use of edible insects as a source of protein [13]. Edible insect consumption could not only reduce the amount of ozone produced by traditional meat production, thus reducing environmental pollution [4], but the production of protein using edible insects is less costly than traditional meat production and far more rapid due to the short breeding period of insects [5]. More than 1,900 species of edible insects are consumed worldwide [6] and edible insects are an important resource for future food security [2,3]. However, edible insects are being ignored by consumers because of their appearance, among other perceptions [7,8]. Therefore, edible insects cannot be used intact, and instead, the proteins from these insects are extracted, dried, and pulverized [4]. Edible insects have a high protein content, but processing them for consumption can be challenging due to the high levels of chitin present in their bodies [9]. Adult edible insects contain much larger amounts of chitin than their larvae; therefore, larvae may present a more suitable insect-based protein source [10,11].

The yellow mealworm (Tenebrio molitor) is a member of the Coleoptera family and is cultivated in Korea and worldwide [6]. T. molitor is mostly used as animal feed or as a protein supplement because it is rich in protein and essential fatty acids. The white-spotted flower chafer (Protaetia brevitarsis) is a carnivorous insect belonging to the Cetoniidae family that undergoes complete transformation from the eggs, larvae, and pupa, to the imago [12]. The Korean rhinoceros beetle (Allomyrina dichotoma), belonging to the Scarabaeidae family, is known to inhabit Korea, Japan, China, and Taiwan. A nutritional analysis of the larvae of these beetles found that they contained high levels of essential unsaturated fatty acids [13].

Among the various types of processed foods, emulsion-type sausages are a popular dish worldwide [14]. Therefore, the development of emulsion-type sausages formulated with edible insects is recommended. However, almost no studies have assessed the manufacture of meat products using edible insect emulsions, and studies have mainly focused on the use of simple protein substitutes.

The aim of this study was to evaluate the physicochemical characteristics of emulsions from T. molitor, A. dichotoma, and P. brevitarsis seulensis, to understand their potential as protein sources and meat substitutes.

MATERIALS AND METHODS

Preparation of emulsions

The larvae of T. molitor (moisture, 63.18 ± 1.04%; protein, 21.53 ± 1.53%; fat, 9.33 ± 0.31%; ash, 1.65 ± 0.11%), P. brevitarsis seulensis (moisture, 79.73 ± 0.59%; protein, 10.35 ± 0.35%; fat, 4.29 ± 0.09%; ash, 1.16 ± 0.02%), and A. dichotoma (moisture, 88.06 ± 0.71%; protein, 2.93 ± 0.16%; fat, 2.93 ± 0.16%; ash, 0.40 ± 0.01%) were purchased from a farm (Jeongeup, Korea), and pork back fat was purchased from a local processor. The larvae and pork back fat were ground (6 mm) with a grinder (PA-82, Mainca, Barcelona, Spain). Three different emulsions were produced: 65% T. molitor, 20% pork back fat, and 15% ice; 65% A. dichotoma, 20% pork back fat, and 15% ice; and 65% P. brevitarsis seulensis, 20% pork back fat, and 15% ice. The ground larvae were homogenized for 2 min using a silent cutter (Cutter Nr-963009, Scharfen, Witten, Germany). Ice water (1°C), 1.5% NaCl, and 0.15% phosphate were added to the ground larvae and mixed for 90 s. Pork back fat was added after 2 min, and the emulsions were homogenized for 2.5 min at temperatures below 10°C. The emulsions were stuffed into a collagen casing (diameter 24 mm) using a stuffer (IS-8, Sirman, Padua, Italy). These formulations were analyzed in triplicate for each emulsion type [14].

pH

The pH of the emulsions was determined in a homogenate prepared from samples (5 g) and distilled water (20 mL) using an electronic pH meter (Model 340, Mettler-Toledo GmbH, Schwerzenbach, Switzerland).

Color

The color of the emulsions was measured with a CR-410 Chroma Meter (Minolta, Osaka, Japan) using the CIE color system, and was calibrated using a standard white plate [CIE L* = +97.83, CIE a* = −0.43, CIE b* = +1.98].

Texture profile analysis (TPA)

Before analysis, the emulsions were cooked at 75°C for 30 min and cooled at 25°C for 2 h. The TPA was conducted using a texture analyzer (TA-XT2i, Stable Micro Systems, Godalming, UK). The TPA conditions were as follows: maximum load, 1 kg; pre-test speed, 1.0 mm/s; post-test speed, 1.0 mm/s; head speed, 1.0 mm/s; distance, 5.0 mm; and force, 1.0 g [15].

Sodium dodecyl sulfate-polyacrylamide gel electrophoresis (SDS-PAGE)

The molecular weight distribution of proteins in the insect-based emulsions was estimated using SDS-PAGE. Chemicals used in this experiment were obtained from Bio-Rad Laboratories (Hercules, CA, USA). After a 10-fold dilution, 20 μL of each sample and 4× sample buffer were mixed well and heated to 100°C for 5 min [16]. Cooled samples were loaded on a 12% Mini-PROTEIN® TGX at 80 mA with a standard marker (Plus Protein TM Dual Color Standards) and the gel was stained with Coomassie brilliant blue R-250.

Apparent viscosity

The apparent viscosity of the emulsions was determined with a Brookfield viscometer (DV3T HB, SC4-29 standard cylinder sensor; Brookfield Engineering Labs, Stoughton, MA, USA). A metal cup filled with emulsion (5 mL) at 17°C was rotated under a continuous shear rate for 35 s [17].

Differential scanning calorimetry (DSC)

A DSC 4000 was used to assess the thermal stability of emulsion samples (DSC 4000, PerkinElmer, Waltham, MA, USA). An empty pan was placed on one side of the sensor and a sealed pan containing 30 μg of sample was placed on the other side. A temperature range of 20°C–120°C was used and the heating rate was maintained at 10°C/min.

Statistical analysis

SPSS Statistics (SPSS, Chicago, IL, USA) was used to analyze the data. The fixed effects were considered when comparing differences among insect species. A one-way ANOVA test was performed with a Duncan’s multiple range comparison test (p < 0.05). All experiments were conducted in triplicate, and emulsions were separately manufactured for each replicate.

RESULTS AND DISCUSSION

pH and color

The pH and color of the emulsions prepared from the edible insect larvae are presented in Table 1. The A. dichotoma emulsion had the highest pH and the T. molitor emulsion had the lowest (p < 0.05). These results are in accordance with those of the study by Kim et al. [8], who observed similar technical functional properties of extracts from edible insects. Kim et al. [18] concluded that the pH of edible insect protein can significantly improve the quality characteristics of the emulsion-type sausages. Mishyna et al. [11] indicated that a higher pH enhanced the quality of edible insect protein and protein functionality.

Table 1. The pH and color of edible insect-based emulsions from three species: Tenebrio molitor, Allomyrina dichotoma and Protaetia brevitarsis seulensis
T. molitor A. dichotoma P. brevitarsis seulensis
pH 6.44 ± 0.02c 7.20 ± 0.11a 6.56 ± 0.02b
CIE L* 43.73 ± 0.01a 29.70 ± 0.03c 34.73 ± 0.05b
CIE a* 4.25 ± 0.03a 1.66 ± 0.02c 3.77 ± 0.03b
CIE b* 12.58 ± 0.01a 3.95 ± 0.09c 7.46 ± 0.02b

All values represent the means ± SDs of three replicates (n = 3); the CIE color system was used to obtain the L*, a*, and b* values.

a–c Means within a row with different letters are significantly different (p < 0.05).

Download Excel Table

The color of the different emulsions is shown in Table 1. The A. dichotoma emulsion had the lowest lightness, redness, and yellowness values (p < 0.05), while the T. molitor emulsion had the highest values (p < 0.05). Similar results were reported by Kim et al. [8], who noted significant differences in the lightness, redness, and yellowness values of proteins extracted from edible insects. Mishyna et al. [11] and Wittkopp and Beldade [19] reported that the color of edible insects was influenced by the melanin content. In this study, the color of emulsions also appears to have been influenced by the melanin content of the insect species.

Texture profile analysis (TPA)

The effects of the insect species on the TPA of the emulsions are presented in Table 2. The T. molitor emulsion had higher hardness, gumminess, and chewiness values (p < 0.05) than the P. brevitarsis seulensis and A. dichotoma emulsions. The P. brevitarsis seulensis and A. dichotoma emulsions had higher springiness and cohesiveness values (p < 0.05) than the T. molitor emulsions. Of the three different larval emulsions, T. molitor showed the poorest protein functionality, which could be due to the poor protein-protein interaction networks among the proteins within this emulsion [9]. This poor interaction induces a low level of water holding capacity and increases the loss of moisture, which leads to an increase in the hardness and a decrease in the springiness and cohesiveness of the emulsions [17]. Kim et al. [2] observed that the heat-induced gel prepared with A. dichotoma was harder than that of the gel prepared with the other treatments, and that all emulsion sausages prepared with edible insects were harder than the control sausages without insects. In this study, T. molitor produced a rigid emulsion and the other species produced more flexible emulsions. These results confirmed that cooked insect emulsions differ in textural properties according to the insect species used. Therefore, to effectively replace meat products with edible insects, it is important that the textural properties of the emulsions are maintained as close to that of traditional meat products.

Table 2. Texture profile analysis (TPA) of edible insect-based emulsions from three species: Tenebrio molitor, Protaetia brevitarsis seulensis, and Allomyrina dichotoma
T. molitor P. brevitarsis seulensis A. dichotoma
Hardness (kg) 0.23 ± 0.04a 0.04 ± 0.01b 0.05 ± 0.01b
Springiness 0.68 ± 0.08b 0.95 ± 0.02a 0.93 ± 0.05a
Cohesiveness 0.49 ± 0.04b 0.60 ± 0.04a 0.62 ± 0.05a
Gumminess (kg) 0.11 ± 0.03a 0.03 ± 0.01b 0.03 ± 0.01b
Chewiness (kg) 0.08 ± 0.02a 0.02 ± 0.00b 0.03 ± 0.01b

All values represent the means ± SDs of three replicates (n = 3).

a,b Means with different letters, within the same row, are significantly different (p < 0.05).

Download Excel Table
Sodium dodecyl sulfate-polyacrylamide gel electrophoresis (SDS-PAGE)

SDS-PAGE can be used to estimate protein distribution based on molecular weight [16]. High-molecular-weight proteins and hydrophobic groups may have stronger network systems [20]. In general, staining agents bind to the hydrophobic sites of proteins, and thus, staining agents can be used to reveal protein molecules [16]. The sample prepared using T. molitor was shown to produce the thickest bands (Fig. 1), followed by that prepared using P. brevitarsis seulensis. Although the P. brevitarsis seulensis emulsion samples had thicker bands compared to the A. dichotoma emulsion samples, a significant difference was not observed in the TPA (Table 2). The proteins extracted from T. molitor had a lower molecular weight than those from the other species, which may be attributed to the technical properties of the proteins [9]. A trend was observed whereby the bigger the size of the insect, the fainter the bands in the SDS-PAGE analysis; however, these differences might be species-specific. Ground edible insect products comprise various components, such as hemolymph, enzyme, muscular protein, and chitin [9]. Furthermore, different body sizes, molecular components, and protein concentrations might affect the molecular distribution of proteins. For example, a high protein concentration could induce an increase in the molecular weight and protein distribution. Of the emulsions prepared from the three insect species evaluated in the present study, the T. molitor emulsion was found to have the best gelling properties.

jast-63-2-417-g1
Fig. 1. Sodium dodecyl sulfate-polyacrylamide gel electrophoresis of emulsions prepared from the larvae of three edible insect species: Tenebrio molitor, Protaetia brevitarsis seulensis, and Allomyrina dichotoma.
Download Original Figure
Apparent viscosity

The apparent viscosity of the emulsions differed significantly among species (Fig. 2). The apparent viscosity of the T. molitor emulsion was higher than that of the other treatments. Kim et al. [2] reported that the apparent viscosity of a P. brevitarsis seulensis gel was higher than that of gels prepared using other treatments. Our results differed due to the correlation between protein and fat in the formulated emulsions. Choi et al. [5] reported that water and oil absorption capacities differ depending on the insect species used, and that this also affects the apparent viscosity, emulsifying capacity, and foaming ability of the emulsions. Therefore, T. molitor, the emulsion of which was shown to have the highest apparent viscosity in the present study, might be more suitable for use in the manufacture of insect based-emulsions compared to other species.

jast-63-2-417-g2
Fig. 2. Apparent viscosity of emulsions prepared from the larvae of three edible insect species: Tenebrio molitor, Protaetia brevitarsis seulensis, and Allomyrina dichotoma.
Download Original Figure
Differential scanning calorimetry (DSC)

The thermal properties of emulsions are important indicators of the thermal stability of proteins [21]. The thermal properties of the insect-based emulsions are shown in Fig. 3. Protein denaturation was observed at temperatures ranging from 60 to 100°C. The distributions for T. molitor and A. dichotoma showed one peak each (at ~80°C and ~72°C, respectively) and that of P. brevitarsis seulensis showed two peaks (at ~80°C and ~72°C). These differences may be attributable to differences in the thermal stability of the proteins that the larvae of these species comprise. Proteins that denature at ~80°C may have a more critical impact on thermal-induced gelling properties than those that denature at ~72°C, as demonstrated by T. molitor showing the highest gelling properties (Table 2).

jast-63-2-417-g3
Fig. 3. Thermal properties of emulsions prepared from the larvae of three edible insect species: Tenebrio molitor, Protaetia brevitarsis seulensis, and Allomyrina dichotoma.
Download Original Figure

CONCLUSION

The physicochemical characteristics and rheological properties of emulsions prepared with various edible insect larvae were investigated. Collectively, our findings suggest that emulsions from T. molitor larvae may be a suitable meat-replacement candidate; specifically, in terms of the texture profile, apparent viscosity, SDS-PAGE results, and DSC findings. Here, we not only confirmed the potential of edible insects as meat protein replacements, but we also provided a technical foundation for the manufacture of various meat products, specifically emulsion-type foods, from edible insects.

Competing interests

No potential conflict of interest relevant to this article was reported.

Funding sources

Not applicable.

Acknowledgements

This research was supported by Main Research Program [E0211200-01] of the Korea Food Research Institute (KFRI) funded by the Ministry of Science and ICT (Korea).

Availability of data and material

Upon reasonable request, the datasets of this study can be available from the corresponding author.

Authors’ contributions

Conceptualization: Kim TK, Jang HW, Choi YS.

Data curation: Yong HI, Sung JM.

Formal analysis: Kim TK, Yong HI, Choi YS.

Methodology: Kim TK, Yong HI.

Software: Kim TK, Jung S.

Validation: Jung S, Sung JM.

Investigation: Kim TK, Choi YS.

Writing – original draft: Kim TK, Jang HW, Choi YS.

Writing – review & editing: Jang HW, Choi YS.

Ethics approval and consent to participate

This article does not require IRB/IACUC approval because there are no human and animal participants.

REFERENCES

1.

Jeon YH, Son YJ, Kim SH, Yun EY, Kang HJ, Hwang IK. Physicochemical properties and oxidative stabilities of mealworm (Tenebrio molitor) oils under different roasting conditions. Food Sci Biotechnol. 2016; 25:105-10

2.

Kim TK, Lee MH, Yu MH, Yong HI, Jang HW, Jung S, et al. Thermal stability and rheological properties of heat-induced gels prepared using edible insect proteins in a model system. LWT-Food Sci Technol. 2020; 134:110270

3.

Lee S, Jo K, Yong HI, Choi YS, Jung S. Comparison of the in vitro protein digestibility of Protaetia brevitarsis larvae and beef loin before and after defatting. Food Chem. 2021; 338:128073

4.

Kim TK, Yong HI, Kim YB, Kim HW, Choi YS. Edible insects as a protein source: a review of public perception, processing technology, and research trends. Food Sci Anim Resour. 2019; 39:521-40

5.

Choi YS, Kim TK, Choi HD, Park JD, Sung JM, Jeon KH, et al. Optimization of replacing pork meat with yellow worm (Tenebrio molitor L.) for frankfurters. Korean J Food Sci Anim Resour. 2017; 37:617-25

6.

Van Broekhoven S, Oonincx DGAB, Van Huis A, Van Loon JJA. Growth performance and feed conversion efficiency of three edible mealworm species (Coleoptera: Tenebrionidae) on diets composed of organic by-products. J Insect Physiol. 2015; 73:1-10

7.

Feng Y, Chen XM, Zhao M, He Z, Sun L, Wang CY, et al. Edible insects in China: utilization and prospects. Insect Sci. 2018; 25:184-98

8.

Kim TK, Yong HI, Jeong CH, Han SG, Kim YB, Paik HD, et al. Technical functional properties of water- and salt-soluble proteins extracted from edible insects. Food Sci Anim Resour. 2019; 39:643-54

9.

Kim TK, Yong HI, Chun HH, Lee MA, Kim YB, Choi YS. Changes of amino acid composition and protein technical functionality of edible insects by extracting steps. J Asia-Pac Entomol. 2020; 23:298-305

10.

Kwak KW, Kim SY, An KS, Kim YS, Park K, Kim E, et al. Subacute oral toxicity evaluation of freeze-dried powder of locusta migratoria. Food Sci Anim Resour. 2020; 40:795-812

11.

Mishyna M, Martinez JJI, Chen J, Benjamin O. Extraction, characterization and functional properties of soluble proteins from edible grasshopper (Schistocerca gregaria) and honey bee (Apis mellifera). Food Res Int. 2019; 116:697-706

12.

Choi MH, Kim KH, Yook HS. Antioxidant activity and quality evaluation of the larvae of protaetia brevitarsis after feeding with Korean panax ginseng. J Korean Soc Food Sci Nutr. 2019; 48:403-9

13.

Ryu HJ, Song HJ, Lee SO. Enzymatic preparation and antioxidant activities of protein hydrolysates from Allomyrina dichotoma larvae. J Korean Soc Food Sci Nutr. 2019; 48:410-7

14.

Uzlaşır T, Aktaş N, Gerçekaslan KE. Pumpkin seed oil as a partial animal fat replacer in bologna-type sausages. Food Sci Anim Resour. 2020; 40:551-62

15.

Bourne MC, Kenny JF, Barnard J. Computer-assisted readout of data from texture profile analysis curves. J Texture Stud. 1978; 9:481-94

16.

Laemmli UK. Cleavage of structural proteins during the assembly of the head of bacteriophage T4. Nature. 1970; 227:680-5

17.

Choi YS, Choi JH, Han DJ, Kim HY, Lee MA, Kim HW, et al. Characteristics of low-fat meat emulsion systems with pork fat replaced by vegetable oils and rice bran fiber. Meat Sci. 2009; 82:266-71

18.

Kim HW, Setyabrata D, Lee YJ, Jones OG, Kim YHB. Pre-treated mealworm larvae and silkworm pupae as a novel protein ingredient in emulsion sausages. Innov Food Sci Emerg Technol. 2016; 38:116-23

19.

Wittkopp PJ, Beldade P. Development and evolution of insect pigmentation: genetic mechanisms and the potential consequences of pleiotropy. Semin Cell Dev Biol. 2009; 20:65-71

20.

Zayas JF. Functionality of proteins in food. Berlin, Germany: Springer. 2012

21.

Heussen P, Ye P, Menard K, Courtney P. Practical food applications of differential scanning calorimetry. Differential scanning calorimetry. Waltham, MA: Perkinelmer. 2011Report No.: 009742_01
